Gatic Slotdrain CastSlot 225mm 0.5m Length

CA00243

GS F900 Load Class

CastSlot 225mm 0.5m Length

Product Attributes
Volumetric Data
Description
Key Features
NBS Source

Product Type	Length
Intake Area/Metre	26350mm2
British Standard	BS EN 1433
NBS Uniclass Reference	Pr_65_52_24_47 Linear slot drainage channels
NBS CAWS Reference	Q10/170 Linear slot drainage channel systems
Material	Galvanised Steel
Invert	452mm
Throat Depth	200mm
Throat Width	51mm
Slot Orifice	30mm
Capacity	45 l/m

Brand: Gatic

Product Family: Slotdrain

Product Range: CastSlot

Metal Type: Galvanised Steel

Load Class: F900

Product Type: simple

Weight: 26.014568 kg kg

Width: 22.5 cm

Length: 50 cm

Height: 45.2 cm

Description

Gatic CastSlot is a robust yet discreet linear slot drainage system engineered for areas with constant or slow‑turning vehicular traffic, such as car parks, industrial yards, ports, and airports. Its unobtrusive profile integrates seamlessly into concrete, asphalt, and block surfaces, while its electro‑painted ductile iron throat securely connects to a galvanized steel channel for long‑term durability. Designed to handle load classifications from A15 up to heavy‑duty F900, CastSlot provides continuous surface water interception with high capacity and minimal wash‑over. A Treadsafe option is available for pedestrian‑frequent areas, reducing the slot width to improve safety. With multiple channel widths and lengths, simple installation features, and compatibility with through‑spacers for cable routing, CastSlot delivers reliable, aesthetic, and low‑maintenance drainage performance for demanding environments.

Features and benefits:

Strong and durable construction using an electro‑painted ductile iron throat and galvanized steel channel body.
Discreet, unobtrusive profile that integrates neatly into concrete, asphalt, or block paving finishes.
High load‑class capability from A15 to F900, suitable for heavy‑duty vehicular environments.
Treadsafe option available, narrowing slot apertures for improved pedestrian safety.
High drainage capacity with efficient intake and continuous interception to reduce wash‑over.
Self‑cleansing channel performance thanks to stepped fall and V‑shaped flow design.
Fewer channel joints due to long standard lengths (up to 3m), improving flow and installation efficiency.
Fast and easy installation with impact‑resistant galvanized steel channels and a secure locking system.
Low maintenance requirements with tamper‑proof design and no movable parts.
Flexible design options including through‑spacer functionality for cable routing and multiple width choices (100–600mm).
